7018 7020 CHIK Bearing Shandong Production Factory High Precision Angular Contact Ball Bearing

Angular contact ball bearings can withstand both radial and axial loads. Can work at higher speeds. The larger the contact angle, the higher the axial load carrying capacity. High precision and high speed bearings typically take a 15 degree contact angle. Under the axial force, the contact angle will increase. Single row angular contact ball bearings can only withstand axial loads in one direction and will cause additional axial forces when subjected to radial loads. And can only limit the axial displacement of the shaft or casing in one direction. If it is installed in pairs, the outer rings of a pair of bearings are opposite, that is, the wide end faces the wide end faces, and the narrow end faces the narrow end faces. This avoids causing additional axial forces and limits the shaft or housing to axial play in both directions.
  • 7018 7020

  • CHIK,SKF,NSK

Availability:
Quantity:

7018 7020 CHIK Bearing Shandong Production Factory High Precision Angular Contact Ball Bearing

Model NO.
7018 7020
Type
angular contact ball bearing
Rolling Body:
Roller Bearing
Precision: P0 P6 P5
Clearance:
C0 C2 C3 C4 C5
Package: Industrial Packing
Vibration:
V1 V2 V3 V4
Rings Material:
Chrome Steel GCR15
Feature:
Low Noise. Long Life .high
Seals Type:
ZZ RS OPEN
Service:
OEM Service, Sample Available
Export Markets:
Global
Quality Control: 100% inspectedSingle rowDouble row Number of Row Single row
Packaging Details:

1.Nuetral package + carton package

2.Carton package + pallet

3.Wood package + pallet

for angular contact ball bearing

Application:

Agricultural Machinery;automobile and motorcycle

63355aa8d8634cb63b28a1254f5ad56a

Bearing      No.

Dimensions (mm)

Weight (kg)


d

D

B


7212C

7212AC

60

110

22

0.80

7213C

7213AC

65

120

23

1.00

7214C

7214AC

70

125

24

1.10

7215C

7215AC

75

130

25

1.20

7216C

7216AC

80

140

26

1.45

7217C

7217AC

85

150

28

1.80

7218C

7218AC

90

160

30

2.25

7219C

7219AC

95

170

32

2.70

7220C

7220AC

100

180

34

3.25

7221C

7221AC

105

190

36

3.85



CHIK BEARING PACKING

1.Poly sleeves +Single box(with chik mark ) +Carton;

2.Industrial packaging ;

3.Customer design (Oem service).


CHIK BEARING DELIVERY

1.Small quantity, can delivery by global express: DHL TNT FedEx ARAMEX EMS UPS. this is door to door.

2.Large quantity, can delivery by air,by sea ,this is port to port.

packing and delivery-1


CHIK BEARING established in 2015, is a professional bearings manufacturer integrating the research, development and sales. We have a floor area of 15,000 square meters and a plant area of 8,800 square,equipped with modern production equipment and advanced detection instruments.Our major products include deep groove ball bearing,tapered roller bearing,spherical roller bearing and other kinds of high precision bearings.


CHIK BEARING has the latest measurement and quality assurance systems,utilizing high quality and precise messuring equipment. with which we conduct all necessary tests to gurantee high quality of entire production.Each production process is also in strict accordance with the ISO9001 quality management system, which effectively guarantees the precise of products and stability of the performance. CHIK bearings have been widely applied to metallurgical, mining, petroleum, chemical, papermaking and engineering machinery industries.

Our Factory

Factory-2



Quality promise

1. What is the market scope?

Our bearings are sold globally,Among them, it is sold to the domestic market (30.00%), North America (8.00%), South America (8.000%), Eastern Europe (8.00%), Nordic Europe (8.00%), Western Europe (7.00%), Southern Europe (7.000%), Southeast Asia (5.00%), Middle East (5.00%), East Asia (5.00%), and Africa (4.00%). We have a professional foreign trade service team of 5-10 people.


2. How can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;


3.What can you buy from us?

Ball Bearing,Roller Bearing.


4. Why should you buy bearing from us?

Chik has been successful cooperation with many overseas customers, leaving good reputation of credibility with a high-quality product quality. With adequate resource, strict quality control, high-quality service, and competitive price.


5. What services can we provide?

Accepted Delivery Terms: FOB,CFR,CIF,EXW;

Accepted Payment Currency:USD;

Accepted Payment Type: T/T,L/C,PayPal,Western Union,Escrow;

Language Spoken:English


For more detailed information, please contact us!
