10Q.630/22.A.F386 20x56x16 BA7/5 Deep Groove Bearing

CHIK supplies SNR 10Q.630/22.A.F386 bearings. This 20x56x16 mm single-row deep groove ball bearing is specified for the input or primary shaft on the side opposite the engine in Peugeot 504 BA7/5 manual gearboxes. Bulk purchasing, OEM packaging and mixed-model sourcing are available for transmission-parts distributors and importers. MOQ: 140 pieces.

Model:
10Q.630/22.A.F386
Brand:
SNR

Size:	20x56x16 mm
Structure Type:	Single-row deep groove ball bearing
Application:	Peugeot 504 manual gearbox
Installation Position:	Input/primary shaft, opposite engine side
Transmission Model:	BA7/5
OE / Cross Reference:	2358.29 / 235830 / 630/22 / 533365
Availability:

Quantity:



Inquire Add to Basket

10Q.630/22.A.F386 Bearing Technical Description

10Q.630/22.A.F386 is a single-row deep groove ball bearing with a 20 mm bore diameter, 56 mm outside diameter and 16 mm width. It is specified for the input or primary shaft on the side opposite the engine in Peugeot 504 BA7/5 manual gearboxes.

The single-row ball-and-raceway structure supports radial loading and moderate axial loading from either direction while locating the rotating shaft in the gearbox assembly. At the verified position, the bearing helps maintain input-shaft alignment and stable rotation during torque transfer.

Before replacement, confirm the complete 10Q.630/22.A.F386 designation, 20x56x16 mm dimensions, installation position and BA7/5 gearbox application. Check OE references 2358.29 and 235830, together with cross references 630/22 and 533365, against the removed bearing or vehicle parts list.
